MS8005D
Hose assembly dimensions for style M: See table XI.
TABLE XI. Hose assembly dimensions for style M. 1/
Fitting ends |
Hose size |
Dimensions 2/ |
|||||||||||
A (nom) |
G (max) |
D (max) |
E (max) |
F (max) |
G (min) |
G (max) |
H (max) |
J (max) |
K (min) |
K (max) |
|||
1 |
2 |
||||||||||||
|
45° |
90° |
8 |
0.438 |
0.880 |
1.722 |
1.332 |
1.014 |
0.445 |
0.632 |
2.495 |
1.938 |
0.810 |
1.060 |
10 |
0.515 |
0.967 |
2.037 |
1.488 |
1.158 |
0.501 |
0.688 |
2.955 |
2.340 |
1.091 |
1.341 |
||
12 |
0.570 |
1.122 |
2.368 |
1.667 |
1.447 |
0.588 |
0.775 |
3.705 |
2.722 |
1.341 |
1.591 |
||
16 |
0.620 |
1.480 |
2.583 |
1.879 |
1.736 |
0.609 |
0.857 |
4.100 |
3.075 |
1.465 |
1.715 |
||
20 |
0.640 |
1.750 |
2.946 |
2.058 |
2.328 |
0.697 |
1.017 |
4.835 |
3.637 |
1.747 |
2.122 |
||
24 |
0.765 |
2.150 |
3.210 |
2.400 |
2.621 |
0.785 |
1.127 |
5.480 |
4.212 |
1.997 |
2.372 |
||
1/ Style M uses class 2 fittings which are made from a combination of aluminum and GRES.
2/ Dimensions are shown on figure 11.
FIGURE 11. Style M hose assembly. Hose assembly dimensions for style N: See table XII.
TABLE XII. Hose assembly dimensions for style N. 1/
Fitting ends |
Hose size |
Dimensions 2/ |
|||||||
1 |
2 |
A (nom) |
G (max) |
F (max) |
H (max) |
J (max) |
K (min) |
K (max) |
|
|
90° |
90° |
8 |
0.438 |
0.880 |
1.014 |
2.495 |
1.938 |
0.810 |
1.060 |
10 |
0.515 |
0.967 |
1.158 |
2.955 |
2.340 |
1.091 |
1.341 |
||
12 |
0.570 |
1.122 |
1.447 |
3.705 |
2.722 |
1.341 |
1.591 |
||
16 |
0.620 |
1.480 |
1.736 |
4.100 |
3.075 |
1.465 |
1.715 |
||
20 |
0.640 |
1.750 |
2.328 |
4.835 |
3.637 |
1.747 |
2.122 |
||
24 |
0.765 |
2.150 |
2.621 |
5.480 |
4.212 |
1.997 |
2.372 |
||
1/ Style N uses class 2 fittings which are made from a combination of aluminum and GRES.
2/ Dimensions are shown on figure 12.
8
