MS8005D
FIGURE 3. Style C hose assembly. Hose assembly dimensions for style D: See table IV.
TABLE IV. Hose assembly dimensions for style D. 1/
Fitting ends |
Hose size |
Dimensions 2/ |
|||||||
1 |
2 |
A (nom) |
C (max) |
D (max) |
E (max) |
F (max) |
G (min) |
G (max) |
|
|
45° |
45° |
3/4 |
0.372 |
0.620 |
1.240 |
0.921 |
0.580 |
0.263 |
0.388 |
4 |
0.375 |
0.620 |
1.490 |
0.979 |
0.654 |
0.302 |
0.427 |
||
5 |
0.380 |
0.680 |
1.495 |
1.009 |
0.726 |
0.320 |
0.445 |
||
6 |
0.380 |
0.750 |
1.610 |
1.079 |
0.798 |
0.369 |
0.494 |
||
8 |
0.438 |
0.880 |
1.722 |
1.332 |
1.014 |
0.445 |
0.632 |
||
10 |
0.515 |
0.967 |
2.037 |
1.488 |
1.158 |
0.501 |
0.688 |
||
12 |
0.570 |
1.122 |
2.368 |
1.667 |
1.447 |
0.588 |
0.775 |
||
16 |
0.620 |
1.480 |
2.583 |
1.879 |
1.736 |
0.609 |
0.857 |
||
20 |
0.640 |
1.750 |
2.946 |
2.058 |
2.328 |
0.697 |
1.017 |
||
24 |
0.765 |
2.150 |
3.210 |
2.400 |
2.621 |
0.785 |
1.127 |
||
1/ Style D uses class 1 fittings which are made from CRES.
2/ Dimensions are shown on figure 4.
FIGURE 4. Style D hose assembly.
3
