MS8005D
FIGURE 6. Style F hose assembly. Hose assembly dimensions for style G: See table VII.
TABLE VII. Hose assembly dimensions for style G. 1/
Fitting ends |
Hose size |
Dimensions 2/ |
||||
1 |
2 |
A (nom) |
B ( max) |
C (max) |
F (max) |
|
|
Straight |
Straight |
8 |
0.438 |
1.465 |
0.880 |
1.014 |
10 |
0.515 |
1.680 |
0.967 |
1.158 |
||
12 |
0.570 |
1.727 |
1.122 |
1.447 |
||
16 |
0.620 |
2.101 |
1.480 |
1.736 |
||
20 |
0.640 |
2.255 |
1.750 |
2.328 |
||
24 |
0.765 |
2.400 |
2.150 |
2.621 |
||
1/ Style G uses class 2 fittings which are made from a combination of aluminum and CRES.
2/ Dimensions are shown on figure 7.
FIGURE 7. Style G hose assembly.
