MIL-DTL-27516G
4.4.3.2.2 Hose assemblies. Hose assemblies if one or more defects are identified, then the entire
production lot shall be screened for that defect and all defects shall be either removed or reworked. A
second inspection sample shall then be selected from the different lot and the sampling tests shall be
performed again. If one or more defects are identified from the second inspection lot then the lot shall be
considered as failed.
4.4.4 Sampling for destructive testing. One hose length shall be randomly selected from each lot and
submitted for inspection. After examining the length of hose in accordance with 4.6.1, the hose shall be
cut approximately 3 feet (914.4 mm) from one end and 15 inches (381 mm) from the other end. These
will provide lengths for the pull test (see 4.6.5) and the burst pressure test (see 4.6.8). Additional lengths
of hose shall be cut from the original length for the remaining tests required. When hose is ordered in
short lengths and is insufficient for tests, the manufacturer shall furnish extra lengths for test purposes.
Samples subjected to destructive testing shall not be supplied as part of the contract or order.
4.4.5 Disposition of first article samples. Unless otherwise specified, after award of the contract or
order, the manufacturer shall forward (1 hose or hose assembly), fabricated from random samples of the
hose or hose assembly. The sample shall be representative of the construction, workmanship,
components, and materials to be used during production. When a manufacturer is in continuous
production of the hose and hose assemblies from one contract to another, submission of additional first
article samples for a new contract may be waived at the discretion of the acquiring activity (see 6.2).
4.4.6 Waivers or deviations to specification requirements. All waivers or deviations to specification
requirements shall be coordinated through the preparing activity; DLA Land and Maritime, Columbus,
Attn: VAI, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Fluidflow@dla.mil.
4.5 Conformance inspection. Conformance inspection shall be performed to determine whether the
products conform to the requirements set forth in this specification.
4.5.1 Inspection of product for delivery. Inspection of product for delivery shall consist of individual
inspections in table XI.
TABLE XI. Individual inspections.
Requirement
Test method
Requirement
Samples
paragraph
paragraph
All hose
Examination of products
assemblies
1-12-inch (305
Adhesion between component parts 1/
mm) length hose
All hose and
Proof pressure
assemblies
1/ Each new lot/batch of bulk hose. This data may be furnished by the hose manufacturer.
4.5.2 Sampling for individual inspections. Fittings for sampling shall be selected from a production lot
4.5.2.1 Nonconformance individual inspections. If a defect is found in the adhesion between
component parts test the lot shall be considered as failed. If a defect is a part of a hose assembly the
hose assembly may be reworked. If one or more defects are found in the second inspection lot, the
production lot shall be rejected and shall not be supplied to this specification. Test data of part
performance shall be made available to the contracting agency upon request.
17
