MIL-DTL-27516G
TABLE VI. Allowable weights of hose. 1/ 2/
Hose ID
Maximum weight
inch (mm)
lb/ft (kg/304.8 mm)
1.00 (25.4)
0.90 (0.41)
1.25 (31.8)
1.00 (0.45)
1.50 (38.1)
1.15 (0.52)
2.00 (50.8)
1.50 (0.68)
2.50 (63.5)
2.15 (0.98)
3.00 (76.2)
2.50 (1.13)
4.00 (101.6)
3.60 (1.63)
6.00 (152.4)
7.00 (3.18)
1/ Dimensions are in inches.
2/ Metric equivalents are given for information only.
3.5 Performance.
3.5.1 Adhesion between component parts. When tested in accordance with 4.6.2, adhesion between
component parts shall be not less than the values specified in table VII.
TABLE VII. Adhesion requirements. 1/ 2/
Unaged adhesion
Aged adhesion
ID of hose
lb/in (kg/25.4 mm)
lb/in (kg/25.4 mm)
Up to and including 3 inches (76.2 mm)
12 (5.44)
9 (4.08)
4 and 6 inches (101.6 and 152.4 mm)
10 (4.53)
5 (2.27)
1/ Dimensions are in inches.
2/ Metric equivalents are given for information only.
3.5.2 Volume increase. When tested in accordance with 4.6.3, the volume increase of the tube and
cover shall be not greater than 50 and 100 percent, respectively.
3.5.3 Tensile strength. When tested in accordance with 4.6.4, the tensile strength of the tube and
cover shall be not less than 600 and 400 psi (4.1 and 2.8 MPa), respectively.
3.5.4 Ultimate elongation. When tested in accordance with 4.6.4, the ultimate elongation of the tube
and cover before immersion shall be not less than 200 percent. After immersion, the ultimate elongation
of the tube and cover shall be not less than 100 percent.
3.5.5 Pull resistance. When tested in accordance 4.6.5, the hose assembly shall not break and the
couplings shall not disconnect from the hose.
3.5.6 Proof pressure. When tested in accordance with 4.6.6 and subjected to the proof pressure
specified in table VIII, leakage shall not occur in the hose or at the couplings. There shall be no signs of
permanent deformation or impending failure.
12
