MIL-DTL-27516G
TABLE V. Classification of hose and hose assembly. 1/ 2/
ID
OD
Hose size
±.031
+.125 / -.062
code
(9.45 mm)
(+38.10/-18.90)
number
inches (mm)
inches (mm)
1.0
1.00 (25.4)
1.50 (38.1)
1.2
1.25 (31.8)
1.75 (44.5)
1.5
1.50 (38.1)
2.00 (50.8)
2.0
2.00 (50.8)
2.50 (63.5)
2.5
2.50 (63.5)
3.13 (79.5)
3.0
3.00 (76.2)
3.63 (92.2)
4.0
4.00 (101.6)
4.66 (118.4)
6.0
6.00 (152.4)
6.81 (173.0)
1/ Dimensions are in inches.
2/ Metric equivalents are given for information only.
3.3.2 Hose assembly configuration. The hose assembly shall meet the requirements as specified
herein. The hose assembly shall consist of the following:
The basic hose (see 3.3.1).
a.
b.
Two reattachable couplings, if required, one at each end of the hose (see 3.3.2.1).
c.
Two or three clamps per coupling (see 3.3.3.3)
Reusable protective caps or plugs for each coupling (see 3.3.3)
d.
3.3.2.1 Hose ends. The ends of the hose shall not be shaved, tapered or have the inner or outer
diameter changed in any way, to facilitate attachment of the couplings. When couplings are not required
the cut hose ends shall be sealed to prevent the entrance of foreign contaminants.
3.3.2.2 Diameter. The inside and outside diameters of the hose shall be within the limits shown in
3.3.2.3 Length of hose assembly. The hose assembly length shall be measured as shown on
figure 2.
8
