MIL-DTL-27516G
The tape shall run longitudinal along the hose and the print information shall be repeated continuously
along the length of the hose.
a.
PIN as described in 1.2, length, configuration, and color designator and may be omitted.
b.
Cure date in quarter and year such as 4Q11 for fourth quarter 2011.
c.
CAGE code.
d.
Manufacturer's name or trademark.
Example : M275161.5 4Q11 CAGE manufacturer's name or trademark.
3.6.2 Tagging of hose assemblies. After the hose is assembled into a hose assembly the hose
assembler shall attach a removable tag to each hose assembly and shall contain the military PIN, date of
assembly, specification number, name, and CAGE code of assembly manufacturer.
Example: M27516G1.5A05006 4Q11 CAGE manufacturer's name or trademark.
3.7 Age limit. The age limit of bulk hose and hose assemblies covered by this specification and
furnished for use by the Government shall not exceed the limits specified in SAE-AS1933. Hose inner
tubing used in the hose assemblies shall have been manufactured not more than two quarters prior to
presentation for acceptance, see 4.6.1
3.8 Workmanship. Workmanship shall be of the quality necessary to produce hose and hose
assemblies free from defects which would adversely affect service performance, see table IX.
TABLE IX. Workmanship defects.
Inspection
Paragraph
Hose ends of the hose shaved or tapered
Inner tube missing; braided, loomed, or plied reinforcement
Inner tube bore shall be smooth, free from pitting, objectionable
cuttings, borings, or cements; and shall have a uniform
Inner tube wall thickness not less than .078 inch (1.98 mm)
Reinforcement shall be well, evenly, and firmly braided, loomed, or
plied, and free from defects, dirt, knots, lumps, and irregularities of
twist
Cover shall be smooth, free from pitting.
Reinforcement through cover
N/A
Cover uniform thickness not less than .047 inch (1.19 mm)
4. VERIFICATION
4.1 Classification of inspection. The inspection requirements specified herein are classified as
follows:
a. First article inspection (see 4.4).
b. Conformance inspection (see 4.5)
4.2 Inspection conditions. Unless otherwise specified, all inspections shall be performed in
accordance with the test conditions specified in the applicable test method referenced in the test
procedures.
14
