MIL-DTL-27516 Hose And Hose Assembly, Nonmetallic, Suction And DischargeThis specification contains the requirements for a non-collapsible, wire reinforced, synthetic rubber hose and hose assembly used with gasoline and jet-fuel.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16

MIL-DTL-27516G

TABLE X. First article test methods.

Requirement

Test method

Requirement

Sample

paragraph

3.2, 3.4, 3.3.1,

3.3.2, 3.3.3,

Examination of product

4.6.1

All hose assemblies

3.6, 3.7 and

3.8

1-12-inch (305 mm)

Adhesion between component parts

3.5.1

4.6.2

length hose

Tube and cover

Volume increase

3.5.2

4.6.3

specimens

Tube and cover

Tensile strength

3.5.3

4.6.4

specimens

Tube and cover

Ultimate elongation

3.5.4

4.6.4

specimens

1-hose assembly 15-

Pull resistance (see 4.4.4) 1/

3.5.5

4.6.5

inch (381 mm)

Proof pressure 1/

3.5.6

4.6.6

All hose assemblies

Length change

3.5.7

4.6.7

1-Hose assembly

Burst pressure (see 4.4.4)

3.5.8

4.6.8

1-hose assembly 3 ft

12-inch (304.8mm)

Crush resistance

3.5.9

4.6.9

hose

Tube and cover

Low temperature bend

3.5.10

4.6.10

specimens

Environmental vacuum

3.5.11

4.6.11

1-hose assembly

Ozone resistance

3.5.12

4.6.12

Cover specimens

1-hose, of sufficient

Sediment and fuel color change

3.5.13

4.6.13

length to contain at

least 4 liters of fluid

1/ This data shall be furnished by the hose assembly manufacturer. All other data may be supplied

from the hose manufacturer or the hose assembly manufacturer.

4.4.3 Inspection lot. All hoses or hose assemblies of the same type and size offered to the

Government at one time shall be considered as a lot for the purpose of inspection.

4.4.3.1 First article samples. The samples shall be representative of the construction, workmanship,

components, and materials to be used during production. When a manufacturer is in continuous

production of the hose assemblies from one contract to another, submission of additional first article

samples for a new contract may be waived at the discretion of the acquiring activity (see 6.2).

4.4.3.2 Nonconformance of first article tests. All samples shall meet all of the contract requirements.

Failure of a sample unit to pass any test shall be cause for rejection of the entire lot and to not grant first

article approval.

4.4.3.2.1 Specimen tests. If a defect is found among samples for adhesion (4.6.2.), volume increase

(4.6.3), tensile strength (4.6.4), ultimate elongation (4.6.4), low temperature bend (4.6.10), ozone

resistance (4.6.12), or fuel color change (4.6.13) the lot shall be considered as failed.
