MIL-DTL-27516G
TABLE IV. Material and color designator.
Material color
Coupling
Material
Color
designator
R
SAE-AS38404, class 1
Brass
N/A
Stainless steel
S
SAE-AS38404, class 2
N/A
or aluminum
T
A-A-59326, class 1
Aluminum
N/A
U
A-A-59326, class 2
Brass
N/A
Non-vivid and lusterless shade of tan.
Blank
A-A-59377
N/A
Valve lever, bumper and dust cap are a
lusterless shade of black.
A
A-A-59377
N/A
FED-STD-595/24052 (semi-gloss green).
B
A-A-59377
N/A
FED-STD-595/33446 (desert tan).
C
A-A-59377
N/A
FED-STD-595/16081 (dark gray).
D
A-A-59377
N/A
FED-STD-595/15044 (dark blue).
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this
specification. This section does not include documents cited in other sections of this specification or
recommended for additional information or as examples. While every effort has been made to ensure the
completeness of this list, document users are cautioned that they must meet all specified requirements
documents cited in sections 3, 4, or 5 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and
handbooks form a part of this document to the extent specified herein. Unless otherwise specified, the
issues of these documents are those cited in the solicitation or contract.
COMMERCIAL ITEM DESCRIPTIONS
A-A-52506
-
Clamps, Hose
A-A-59326
-
Coupling Halves, Quick-Disconnect, Cam-Locking Type, General
Specification For
A-A-59326/2
-
Coupling Half, Male by Hose Shank, Type II
A-A-59326/6
-
Coupling Half, Female by Hose Shank, Type VI
A-A-59326/10
-
Coupling Half, Cap, Dust, Type IX
A-A-59326/11
-
Coupling Half, Plug, Dust, Type X
A-A-59377
-
Coupling Assembly, Quick-Disconnect, Sexless Type
DEPARTMENT OF DEFENSE SPECIFICATIONS
MIL-DTL-83420
-
Wire Rope, Flexible, for Aircraft Control
MIL-PRF-16173
-
Corrosion Preventive Compound, Solvent Cutback, Cold-Application
MIL-PRF-24635
-
Coating Systems, Weather-Resistant, Exterior Use
MIL-PRF-85285
-
Coating: Polyurethane, Aircraft and Support Equipment
MIL-PRF-85582
-
Primer Coatings: Epoxy, Waterborne
4
