MIL-DTL-5593E
TABLE II. Workmanship defects.
Defect
Inspection
Reference
Standard inspection
Dimensions affecting
equipment
interchangeability not within
(SIE)
tolerance
Ridge on tube - Severe
SIE
N/A
Bunching of tube - Severe
SIE
N/A
Loose tube
SIE
N/A
Off center -under gage cover
SIE
N/A
Hole in tube
SIE
N/A
Nad lap or delamination of tube
SIE
N/A
Reinforcement through tube
SIE
N/A
Reinforcement through cover
Visual
N/A
Poorly patched cover
Visual
N/A
Blistered or loose, patch on cover
Visual
N/A
Under gage cover area
Visual
N/A
Poor coverlap, opening or lack of
Visual
N/A
adhesion
Cover missing
Visual
N/A
Loose cover (wrinkles when
Visual
N/A
bent)
Exposed reinforcement braid
Visual
N/A
Depressed area, groove
Visual
longitudinal corrugations
(exceeding specified tolerance)
Split, slit or break in cover
Visual
N/A
Blister under cover
Visual
N/A
Hose inside diameter at fitting
SIE
junction out of tolerance
(hose assembly only)
Misbranding
Visual
4. VERIFICATION
4.1 Classification of inspection. The inspection requirements specified herein are classified as
follows:
a. Qualification inspection (see 4.4).
b. Conformance inspection (see 4.5).
4.2 Inspection conditions. Unless otherwise specified, all inspections shall be performed in
accordance with the test conditions specified in herein or in accordance with ASTM D380 as applicable in
accordance with the applicable test method referenced in the test procedures. Unless otherwise
specified, room temperature shall be defined as +60°F to +90°F (15.56°C to 32.22°C).
4.2.1 Test equipment and inspection facilities. Test and measuring equipment and inspection
facilities of sufficient accuracy, quality, and quantity to permit performance of the required inspection shall
be established and maintained by the contractor. The establishment and maintenance of a calibration
system to control the accuracy of the measuring and test equipment (i.e. Industry Standard, Military
Standard, etc.) shall be in accordance with NCSL-Z540.1 or equivalent.
7
