MS8007C
Hose assembly dimensions for style H: See table VIIl.
TABLE VIII. Hose assembly dimensions for style H. 1/
Fitting ends |
Hose size |
Dimensions 2/ |
|||||||||
1 |
2 |
A (nom) |
C (max) |
F (max) |
H (max) |
J (max) |
K (min) |
K (max) |
M (max) |
p (max) |
|
|
90° |
Straight |
8 |
0.438 |
0.880 |
1.014 |
2.495 |
1.938 |
0.810 |
1.092 |
1.560 |
0.875 |
10 |
0.515 |
0.967 |
1.158 |
2.995 |
2.340 |
1.056 |
1.341 |
1.570 |
1.000 |
||
12 |
0.570 |
1.122 |
1.447 |
3.705 |
2.722 |
1.341 |
1.591 |
1.640 |
1.250 |
||
16 |
0.620 |
1.480 |
1.736 |
4.100 |
3.075 |
1.465 |
1.840 |
1.750 |
1.500 |
||
20 |
0.640 |
1.750 |
2.328 |
4.835 |
3.637 |
1.747 |
2.233 |
1.990 |
1.844 |
||
24 |
0.765 |
2.150 |
2.621 |
5.480 |
4.212 |
1.997 |
2.372 |
2.260 |
2.125 |
||
1/ Style H uses class 1 fittings which are made from CRES.
2/ Dimensions are shown on figure 8.
FIGURE 8. Style H hose assembly. Hose assembly dimensions for style J: See table lX.
TABLE IX. Hose assembly dimensions for style J. 1/
Fitting ends |
Hose size |
Dimensions 2/ |
||||||||||||
A (nom) |
C (max) |
D (max) |
F (max) |
H (max) |
J (max) |
K (min) |
K (max) |
N (max) |
p (max) |
R (min) |
R (max) |
|||
1 |
2 |
|||||||||||||
|
90° |
45° |
8 |
0.438 |
0.880 |
1.722 |
1.014 |
2.495 |
1.938 |
0.810 |
1.092 |
0.606 |
0.875 |
0.303 |
0.428 |
10 |
0.515 |
0.967 |
2.037 |
1.158 |
2.955 |
2.340 |
1.056 |
1.341 |
0.658 |
1.000 |
0.340 |
0.465 |
||
12 |
0.570 |
1.122 |
2.368 |
1.447 |
3.705 |
2.722 |
1.341 |
1.591 |
0.789 |
1.250 |
0.433 |
0.558 |
||
16 |
0.620 |
1.480 |
2.583 |
1.736 |
4.100 |
3.075 |
1.465 |
1.840 |
0.929 |
1.500 |
0.470 |
0.657 |
||
20 |
0.640 |
1.750 |
2.946 |
2.328 |
4.835 |
3.637 |
1.747 |
2.233 |
1.020 |
1.844 |
0.534 |
0.721 |
||
24 |
0.765 |
2.150 |
3.210 |
2.621 |
5.480 |
4.212 |
1.997 |
2.372 |
1.186 |
2.125 |
0.589 |
0.839 |
||
1/ Style J uses class 1 fittings which are made from CRES.
2/ Dimensions are shown on figure 9.
6
