MIL-DTL-83797 Hose, Rubber, Lightweight, Medium Pressure, General Specification ForThis specification covers the general requirements for hose, rubber, lightweight, medium pressure, with operating limits of -65 to 250 Degrees F and 200 to 1000 psi suitable for aircraft fuel and oil systems within the limits specified herein.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18

MIL-DTL-83797C

Braid detail

Wt. Max

Inner

Outer

braid

Hose

size

Wire

lbs./in.

gram/25.4 mm

inches

(mm)

-03

.008 (0.20)

0.008

3.63

-04

.008 (0.20)

0.010

4.54

-05

.008 (0.20)

0.012

5.44

-06

.008 (0.20)

0.013

5.90

-08

.008 (0.20)

0.017

7.71

-10

.008 (0.20)

0.022

9.98

-12

.008 (0.20)

0.026

11.79

-16

.010 (0.25)

.008 (0.20)

0.037

16.78

-20

.010 (0.25)

0.051

23.13

-24

.016 (0.41)

.010 (0.25)

0.069

31.30

-32

.016 (0.41)

.012 (0.30)

0.085

38.56

NOTES:

1. Dimensions are in inches.

2. Metric equivalents are given for information only.

3. Identification: See 3.5 and 6.1.

4. Unless otherwise specified, tolerances: decimals, � .010 inch (0.25 mm) except for wire braid

which will be in accordance with current industry standards.

FIGURE 1. Hose construction - Continued.

3.4.1 Hose. The hose shall consist of seamless compounded inner tube of oil resistant synthetic

rubber or copolymer and of uniform gage, reinforced with 18-8 corrosion-resistant steel wire in a manner

to meet the requirements of this specification and retain end fittings, in accordance with MIL-DTL-83798,

without leakage or other malfunction when tested as specified herein.

3.4.2 Length of bulk hose.

3.4.2.1 R designator of bulk hose lengths. Bulk hose shall be furnished in lengths greater than 20

feet (6.10 m). However, up to 10% of the order may be furnished in random lengths between 10 and 20

feet (3.05 to 6.10 m). No more than 10% of the order shall be furnished in random lengths between 3 and

10 feet (0.91 to 3.05 m).

3.4.2.2 S designator for specific bulk hose lengths. When the order is for a specific length in feet, a

tolerance of �1% of the required length shall be used.

3.5 Performance.

3.5.1 Examination of product. The hose shall conform to the requirements of 3.7, 3.8, 3.9, and on

figure 1 when visually examined as specified in 4.7.1.

3.5.1.1 Cleanliness check. The hose shall be free of all foreign material, both internally and

externally, which could adversely affect performance and reliability when examined as specified in

4.7.1.1.
