MIL-DTL-83797 Hose, Rubber, Lightweight, Medium Pressure, General Specification ForThis specification covers the general requirements for hose, rubber, lightweight, medium pressure, with operating limits of -65 to 250 Degrees F and 200 to 1000 psi suitable for aircraft fuel and oil systems within the limits specified herein.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18

MIL-DTL-83797C

Hose Dimensions

Concentric

Equivalent

OD to ID

Hose

inner

over

full indicator

size

tube

braid

movement

inches

inches (mm)

.156 � .015

.376 � .022

-03

.188 (4.78)

.020 (0.51)

(3.96 �0.38)

(9.55 � 0.56)

.219 � .015

.440 � .022

.020 (0.51)

-04

.250 (6.35)

(5.56 � 0.38)

(11.18 � 0.56)

.281 � .015

.486 � .022

-05

.313 (7.95)

.020 (0.51)

(7.14 � .038)

(12.34 � 0.56)

.344 � .015

.549 � .022

-06

.375 (9.53)

.020 (0.51)

(8.74� 0.38)

(13.94 � 0.56)

.438 � .023

.651 � .022

.020 (0.51)

-08

.500 (12.70)

(11.13 � 0.58)

(16.54 � 0.56)

.562 � .023

.797 � .023

-10

.625 (15.88)

.020 (0.51)

(14.27 � 0.58)

(20.24 � 0.58)

.688 � .023

.938 � .023

-12

.750 (19.05)

.030 (0.76)

(17.48 � 0.58)

(23.83 � 0.58)

.875 � .031

1.156 � .031

.030 (0.76)

-16

1.000 (25.40)

(22.23 � 0.79)

(29.36 � 0.79)

1.125 � .031

1.437 � .031

-20

1.250 (31.75)

.030 (0.76)

(28.58 � 0.79)

(36.50 � 0.79)

1.375 � .031

1.703 � .031

-24

1.500 (38.10)

.030 (0.76)

(34.93 � 0.79)

(43.26 � 0.79)

1.773 � .023

2.101� .039

.030 (0.76)

-32

2.000 (50.80)

(45.03 � 0.58)

(53.37 � 0.99)

FIGURE 1. Hose construction.
