INCH-POUND
MIL-DTL-83797C
20 October 2008
SUPERSEDING
MIL-DTL-83797B
18 September 2000
DETAIL SPECIFICATION
HOSE, RUBBER, LIGHTWEIGHT, MEDIUM PRESSURE,
GENERAL SPECIFICATION FOR
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the general requirements for hose, rubber, lightweight, medium
pressure, with operating limits of -65 to 250 °F and 200 to 1000 psi suitable for aircraft fuel and oil
systems within the limits specified herein.
1.2 Part or Identifying Number (PIN). The PIN consists of the letter M, the basic specification number,
a dash, a number for hose size, a dash, three numbers for length a dash, and a number for fractions of an
inch or for bulk hose lengths the letter R or S.
M
83797
-10
-
096
-
6
Blank "-R" or "-S" (see 1.2.1.3)
Fractional lengths in 1/8 inch increments (1 thru 7)
(see 1.2.1.2)
Length in inches or feet (see 1.2.1.1)
Hose size dash number (see figure 1)
Specification number
M prefix
PIN example: M83797-10-096-6 defines a hose; with a 5/8 OD tube, 96 3/4 inches long.
Comments, suggestions, or questions on this document should be addressed to: Defense Supply Center,
Columbus, Attn: DSCC-VAI, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to FluidFlow@dla.mil.
Since contact information can change, you may want to verify the currency of this address information
using the ASSIST Online database at https://assist.daps.dla.mil.
AMSC N/A
FSC 4720
