MIL-DTL-27267D
1.2.1 Hose lengths.
1.2.1.1 Lengths of single hose. Lengths of single hose are represented by inches and fraction of an
inch.
1.2.1.2 Fractions. Fractions are expressed in 1/8 inch increments (0 through 7). Not applicable to
bulk or specific hose lengths.
1.2.1.3 Bulk hose lengths. Bulk hose lengths are represented by the letter B or S and are in feet.
Bulk lengths "B" are in supplied as various ranges of lengths. Increments in percent are specified in
table I.
TABLE I. Percentage of hose length per full order.
Lengths ranging
Dash sizes
Lengths above 14 ft
from 3 to 14 ft 1/
-4, -5, -6, and -8
65% minimum
35% maximum
-10, -12, and -16Z
55% minimum
45% maximum
-20Z and -24Z
40% minimum
60% maximum
1/ Hoses of 3-foot lengths should not be more than 5 percent of the full order.
Example: If 100 feet of bulk hose is ordered the manufacturer may supply hose lengths of 5, 6, 14,
15, 20, and 40 feet. 33.33% of the order has lengths 3 to 14 feet and 66.67% of the order has lengths
longer than 14 feet.
1.2.1.4 Specific length. The "S" designator is used to define specific continuous lengths in feet (see
3.4.5.1).
Note: For the inch designator insert the number zero in front of the designator for lengths less than
100 inches.
Examples:
When 12 7/8 length is required the designator is: 012-7
When 96 inches is required the designator is: 096-0
When 95 feet total length is required the designator is: 095-B
When 35 feet continuous length is required with a tolerance of 1% the designator is: 035-S
2. APPLICABLE DOCUMENTS
specification. This section does not include documents cited in other sections of this specification or
recommended for additional information or as examples. While every effort has been made to ensure the
completeness of this list, document users are cautioned that they must meet all specified requirements
2
