MIL-DTL-17505F
X
XX
XX
MP17505F X
Federal specification number
Hose size code letter (see 6.4.1)
End connections code number (see 6.4.2)
Length in feet (mm)
Length in inches (mm)
6.4.1 Hose size. Hose size is designated by one code letter (see table IV).
TABLE IV. Hose size code letter.
Hose size code letter
A
B
C
D
Hose id (inches (mm))
4 (102 mm)
6 (152 mm)
8 (203 mm)
12 (305 mm)
6.4.2 End connections material. Material of hose is designated by a one-digit code number
(see table V).
TABLE V. Hose end connections material code numbers.
End connection
Material
material
End
Swivel
code number
connections
Nipple
Flange
coupling
1
Flanges and
Steel
Steel
nipples
2
Flanges and
Aluminum
Aluminum
nipples
3
Flanges and
Bronze
Bronze
nipples
4
Flanges and
Brass
Brass
nipples
5
Swivel couplings
Composition A of
and nipples
MIL-F-19488
6.5 End fittings. The 4-inch integral swivel couplings as specified in 3.4.4.1 and 3.4.7 may be
obtained from Moon-Allenco, Easton, PA, with the designation "2950 Integral Nipples." End
fittings specified in 3.4.4.2 may be obtained from Mulconroy Division, Dixon Valve and Coupling
Company, Philadelphia, PA, with the designation Mulconroy style TM "Holedall" coupling.
6.6 Sampling procedures.
6.6.1 Sampling for examination. Examination shall be based on inspection level II and
Acceptable Quality Level (AQL) of 2.5 percent defective for major defects and 4.0 percent
defective for minor defects (see 4.5.1).
14
