MS8009c
Hose assembly dimensions for style M: See table Xl.
TABLE XI. Hose assembly dimensions for style M. 1/
Fitting ends |
Hose size |
Dimensions 2/ |
||||||||||
c (max) |
D (max) |
N (max) |
p (max) |
R (min) |
R (max) |
S (max) |
T (max) |
u (min) |
u (max) |
|||
1 |
2 |
|||||||||||
|
45° |
90° |
8 |
0.880 |
1.722 |
0.606 |
0.875 |
0.303 |
0.428 |
2.320 |
1.422 |
0.857 |
0.982 |
10 |
0.967 |
2.037 |
0.658 |
1.000 |
0.340 |
0.465 |
2.875 |
1.499 |
0.861 |
1.015 |
||
12 |
1.122 |
2.368 |
0.789 |
1.250 |
0.433 |
0.558 |
3.606 |
1.807 |
1.032 |
1.246 |
||
16 |
1.480 |
2.583 |
0.929 |
1.500 |
0.470 |
0.657 |
3.981 |
2.174 |
1.156 |
1.434 |
||
20 |
1.750 |
2.946 |
1.020 |
1.844 |
0.534 |
0.721 |
4.435 |
2.590 |
1.344 |
1.715 |
||
24 |
2.150 |
3.210 |
1.186 |
2.125 |
0.589 |
0.839 |
5.075 |
3.103 |
1.516 |
2.028 |
||
1/ Style M uses class 2 fittings which are made from a combination of aluminum and cRES.
2/ Dimensions are shown on figure 11.
FIGuRE 11. Style M hose assembly. Hose assembly dimensions for style N: See table XIl.
TABLE XII. Hose assembly dimensions for style N. 1/
Fitting ends |
Hose size |
Dimensions 2/ |
||||||
c (max) |
p (max) |
S (max) |
T (max) |
u (min) |
u (max) |
|||
1 |
2 |
|||||||
|
90° |
90° |
8 |
0.880 |
0.875 |
2.320 |
1.422 |
0.857 |
0.982 |
10 |
0.967 |
1.000 |
2.875 |
1.499 |
0.861 |
1.015 |
||
12 |
1.122 |
1.250 |
3.606 |
1.807 |
1.032 |
1.246 |
||
16 |
1.480 |
1.500 |
3.981 |
2.174 |
1.156 |
1.434 |
||
20 |
1.750 |
1.844 |
4.435 |
2.590 |
1.344 |
1.715 |
||
24 |
2.150 |
2.125 |
5.075 |
3.103 |
1.516 |
2.028 |
||
1/ Style N uses class 2 fittings which are made from a combination of aluminum and cRES.
2/ Dimensions are shown on figure 12.
8
