MIL-DTL-83796/9C
TABLE II. Size code. 1/ 2/
Dash number
-08
-10
-12
-16
-20
-24
-32
Size code
H
J
K
M
N
P
R
Inches
1/2
5/8
3/4
1
1 1/4
1 1/2
2
fraction
Hose OD
Inches
.500
.625
.750
1.000
1.250
1.500
2.000
reference
decimal
mm
12.70
15.88
19.05 25.40
31.75
38.10
50.80
1/ Dimensions are in inches.
2/ Metric equivalents are given for information only.
Materials and finishes shall be in accordance with MIL-DTl-83796 and in table III.
TABLE III. Material and finish code.
Part or
Identifying
Material
Plating finish
Number (PIN)
code dash letter
Blank
Aluminum
Anodize in accordance with MIL-A-8625, type II
Anodized in accordance with SAE-AMS2488,
-T
Titanium
type 2 or fluoride phosphated in accordance
with SAE-AMS2486
PIN example:
M83796
/9
H
08
2
F
06
T
Material/finish (see table III)
Angle between elbows to be specified in
5° increments, 30° / 5° = 06 (see figure 3)
Style (see figure 1)
Length in eighths of an inch (0 through 7)
Length in inches (see figure 2)
Size code (see table II)
Specification sheet number
Specification number
M83796/9H082F06T indicates - Hose assembly for ½ hose OD, 8 1/4 inches in length, style F, 30°
between elbows, titanium alloy.
Changes from previous issues. Marginal notations are not used in this revision to identify changes
with respect to the previous issue due to the extent of the changes.
5
