MIL-DTL-28693A
4.5.3.4 Sampling for volume change after immersion (friction rubber). A vulcanized sample of the
rubber friction used to impregnate the fabric reinforcement shall be provided for the volume change after
immersion (see 4.7.9.4). The sample shall be 6 inches by 6 inches by .080 ±.010 inch (15.24 cm by
15.24 cm by 2.03 ±0.25 mm), and shall have the same composition as the friction used in the hose and
an equivalent cure.
4.5.4 First article inspection routine. All samples shall be subjected to first article testing as
specified in table II. The test sequence shall be determined by the manufacturer unless otherwise
specified.
TABLE II. First article inspection.
Requirement
Test
Test
paragraph
paragraph
Visual examination 1/
Unit weight
(prior to assembly of couplings) 1/
Proof pressure 1/
Dimensional stability
Air pressure test 2/
Burst pressure
Tensile pull and elongation
Flexibility test
Properties of rubber components 3/
Initial tensile properties
Tensile properties after immersion
Tensile properties after oven aging
Volume change after immersion
Initial adhesion
Adhesion after immersion
Nonvolatile extractable material
Phosphate plasticizer test
Resistance to ozone
Low temperature bend test
Hose support ring test
1/ 100 percent inspection.
2/ If any hose fails to meet the requirements for air pressure testing the entire lot shall be
rejected.
3/ Rubber samples.
4.5.4.1 Waivers or deviations to specification requirements. All waivers or deviations to
specification requirements shall be coordinated through the preparing activity; Defense Supply Center,
Columbus, Attn: VAI, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
4.5.4.2 Failures. All samples shall meet all of the contract requirements. Failure of a sample unit to
pass any test shall be cause for rejection of the entire lot and refusal to grant first article approval.
11
