A-A-59567/5
TABLE III. PIN codes for class B, style, thread, and clamp.
Class AA
A-A-52506 hose clamp
Ferrule
Thread
coupling
Style
type designator
see
type
PIN code
(see figure 5)
A-A-59614
Short
9N
NH
shank
Short
9P
NPSH
shank
Short
shank -
9Q
NH
handles on
both
Short
shank -
9R
NPSH
handles on
both
A, B, C, D,
R
E, F
Long
9S
NH
shank
Long
9T
NPSH
shank
Long
shank -
9U
NH
handles on
both
Long
shank -
9V
NPSH
handles on
both
Expansion
9W
NH
---
---
ring
Expansion
9X
NPSH
---
---
ring
Expansion
ring
9Y
NH
---
---
handles on
both
Expansion
ring
9Z
NPSH
---
---
handles on
both
Materials. Long handle couplings shall be cast or machined from aluminum, copper alloy (brass),
corrosion resistant steel, or steel, see table IV.
