MIL-DTL-8795G
3.4 Age limits. The age of the hose shall not exceed the age limits specified in SAE-AS1933.
3.5 Identification of product. Each hose assembly shall be identified with a durable permanently
attached tag plainly marked with the following:
a.
Hose assembly PIN from the applicable specification sheet (see 1.2).
b.
Date of assembly (in quarter of year and year).
c.
Commercial and Government Entity (CAGE) Code of the assembler.
d.
Length shall be specified by four digits, with the last digit to indicate fractions in eights of an
inch.
3.6 Workmanship. Hose assemblies shall be free from oil, grease, dirt, or other foreign materials,
both internally and externally, and shall be free of irregularities or defects that could adversely affect
performance. Components of the hose assembly shall not be degraded from their individual performance
capability as the result of assembly.
4. VERIFICATION
4.1 Conformance inspection.
4.1.1 QPL manufacturers. When the hose assembly manufacturer is also listed on the QPL for the
hose (MIL-DTL-8794) and fittings (MIL-DTL-5070) used for the hose assembly, conformance inspection
shall be waived.
4.1.2 Individual inspection. Each hose assembly shall be subjected to the individual inspection
consisting of the inspections specified in table II.
TABLE II. Individual inspection.
Requirement
Inspection
Inspection
paragraph
paragraph
Examination of product
Proof pressure
4.1.2.1 Individual inspection sampling. Individual inspection tests specified in table II shall be
performed on a production lot basis. All defective material shall be removed from the production lot and
shall not be supplied to this specification.
4.1.2.2 Periodic sampling inspection. Periodic sampling inspection shall consist of inspections in
table III. At least one hose assembly shall be selected at random from the inspection lot. For each size
manufactured under essentially the same conditions, periodic sampling inspection shall be performed on
either four samples from every 10,000 hose assemblies produced or one sample from every 2,500 hose
assemblies. If there has been some production but the number hose assemblies produced has not
reached 2,500 for a specific size within three years, the manufacturer shall perform periodic sampling
inspection on one hose assembly of that size.
6
