MIL-DTL-8788F
TABLE III. Qualification and verification of qualification inspection.
Requirement
Test method
Number of
Inspection
samples 1/
paragraph
paragraph
Examination of product
All
and 3.10
Cleanliness
1 hose
Proof pressure
All
Diameter reduction
2 hoses
3 hoses
Elongation and contraction
assemblies
Leakage
2 hoses
Burst pressure
2 hoses
Impulse
4 hoses
Impulse test
Bulge resistance
samples
2 hoses/ or
Low temperature flexibility
hose
assemblies
4.4.3 Acceptance of hose assembly qualification inspection data. Required qualification tests at the
hose assembly level that were already performed at the bulk hose level may be waived if documented
approval has been obtained from the qualifying activity.
4.4.4 Alternate qualification inspection criteria. Hose shall meet the requirements of 4.4.2.
Alternatively, when the identical fittings are manufactured and tested in accordance with MIL-DTL-8789,
and identical hose assemblies are manufactured and tested in accordance with MIL-DTL-8790, using
identical hose in accordance with MIL-DTL-8788, it is not necessary to test the hose to meet the
qualification requirements of this specification at the discretion of the qualifying activity. This applies
when substantially identical test requirements and test procedures are required for the assembly and the
individual components and upon documented approval by the qualifying activity.
4.4.5 Failures. One or more failures shall be cause for refusal to grant qualification approval.
4.4.6 Summary of test. If the summary of test results indicates nonconformance with the
requirements specified herein but the corrective measures acceptable to the qualifying activity has not
been taken, action may be taken to remove the failing product from the QPL.
4.5 Conformance inspection.
4.5.1 Individual inspections. Inspection of the product, for delivery, shall consist of subjecting each
hose length to the individual tests specified in table IV. Any hose failing to meet the requirements of the
individual tests shall be immediately removed from the lot.
10
