MIL-DTL-83796/7D
REQUIREMENTS
Hose assemblies shall be as specified on figures 1, 2, and 3.
Fitting end shall mate with SAE-AS33514 and fitting flange shall mate with MS20756. Flange
installation shall be in accordance with MS33786 as applicable.
Hose assembly length tolerance shall be in accordance with MIL-DTL-83796.
Size codes shall be as specified in table II. Flange fittings are not available for sizes -03, -04, -05,
and -06.
TABLE II. Size code. 1/ 2/
Dash number
-08
-10
-12
-16
-20
-24
-32
Size code
H
J
K
M
N
P
R
Inches
1/2
5/8
3/4
1
1 1/4
1 1/2
2
fraction
Hose OD
Inches
.500
.625
.750
1.000
1.250
1.500
2.000
reference
decimal
mm
12.70
15.88
19.05
25.40
31.75
38.10
50.80
1/ Dimensions are in inches.
2/ Metric equivalents are given for information only.
Materials and finishes for hose fittings shall be in accordance with MIL-DTL-83798 and table III.
TABLE III. Material and finish code.
Material and
Material
Plating finish
finish code
Blank
Aluminum
Anodize in accordance with MIL-A-8625, type II
Anodized in accordance with SAE-AMS2488,
T
Titanium 1/ type 2 or fluoride phosphated in accordance
with SAE-AMS2486
1/ Not to be used in oxygen systems.
