MIL-DTL-52471/9B
PIN: The PIN consists of the letter "M" the specification sheet number a dash, hose size number, a
dash, a three digit number for length of hose (inches for specific lengths, feet for bulk lengths), a dash
and the letter B or S for bulk lengths or a number for 1/8's of an inch.
52471/9
-12
-098
-4
M
1/8's of an inch length
(0 through 7) or "B" or "S" for bulk
lengths see MIL-DTL-52471
Length of hose in inches.
Bulk lengths in feet
(Three digits use leading zeros as required)
Hose size dash number
Specification sheet number
M prefix
PIN examples:
M52471/9-8-16-500-B (1/2 inch hose 500 feet long).
M52471/9-12-096-3 (3/4 inch hose 96 and 3/8 inches long).
Changes from previous issue. Marginal notations are not used in this revision to identify changes
with respect to the previous issue, due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-52471, this document references the following:
ISO 4397
SAE-J517
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Army - CR4
DLA - CC
Navy - SH
Air Force - 99
(Project 4720-2007-025)
DLA - CC
Review activities:
Army - AT, GL
Navy - CG, MC, SA
NOTE: The activities listed above were interested in this document as of the date of this document.
Since organizations and responsibilities can change, you should verify the currency of the information
above using the ASSIST Online database at https://assist.daps.dla.mil.
3
