MIL-DTL-52471/3C
Supersession data. Table VIII shows the suggested replacement hoses for the discontinued
SAE-J517 type 100R10 hose.
TABLE VIII. Alternate hose types to SAE-J517 type 100R10.
Hose
J517 alternate
Operating pressure
ID
Reinforcement
100R10
psi (MPa), [ISO]
dash
number
-12
100R13-12
5000 (34.5), [35.0]
Multiple spiral steel wire reinforced
-16
100R13-16
4000 (27.6), [28.0]
Multiple spiral steel wire reinforced
-20
100R12-20
3000 (20.7), [21.0]
Multiple spiral steel wire reinforced
-24
100R12-24
2500 (17.2). [17.5]
Four-spiral-wrap reinforcement
-32
100R12-32
2500 (17.2), [17.5]
Four-spiral-wrap reinforcement
REQUIREMENTS:
The hose assemblies shall be specified on figure 1 and tables I through VII.
Connector fittings for hose assemblies shall be in accordance with MIL-DTL-52525.
PIN example: The PIN consists of the letter "M" the specification sheet number, an assigned code
number for the hose assembly, material/plating designsator, hose assembly length, and angular
relationship of fittings, when applicable.
52471/3
-C216
C
-098
-4
-135
M
Displacement angle of bent tube fittings
Angular relationship in degrees 1/
(Three digits use leading zeros as required)
See MIL-DTL-52471
1/8's of an inch length
(0 through 7)
Length of assembly in inches
(see MIL-DTL-52471) (Three digits use
leading zeros as required)
Material/plating see table VII
Hose assembly code number
(See tables I through VI)
Specification sheet number
M prefix
1/ Not applicable for assemblies with straight fittings.
PIN example: M52471/3-C116-098-4-135, describes a hose assembly consisting of M52471/6-66
hose, fitting X M52525/15-16-16, bend angle 90°, fitting Y M52525/44-16, bend angle 45°, steel with
cadmium plating, 98 ½ inches long, and a displacement angle of 135°.
To the users of this document, it is recommended that the use of carbon steel material with cadmium
plating be used only when the other materials and finishes specified in this document cannot meet
7
