A-A-59567/1
FIGURE 2. Hose clamp types.
Compression ferrule. Compression ferrule shall be in accordance with A-A-59614, see table IV for
material designators.
TABLE IV. Ferrule material designators.
Designator
Material
CA
Copper alloy (brass)
R
Corrosion resistant steel
Z
Zinc-coated steel
Clamps and ferrules. Clamps or ferrules shall not extend closer than .062 inch to the end of the shank.
Long shank. Long shank hose assemblies shall have two or more clamps for sealing of couplings to
hose.
NOTES.
PIN. The PIN should be used for Government purposes to buy commercial products to this CID.
Source of documents.
COMMERCIAL ITEM DESCRIPTIONS
A-A-52506
-
Clamps, Hose
A-A-59567
-
Hose and Hose Assemblies, Rubber (Yarn or Fabric Reinforced) Water
Service
A-A-59614
-
Coupling Assembly, Hose (Garden, Water, and Water Suction)
A-A-59614/1
-
Coupling Assembly, Hose (Garden, Water, and Water Suction), Short
Shank with Octagon or Hex Swivel, Style 1, Type I
5
