MIL-PRF-53027B(AT)
4.4 Methods of inspection.
4.4.1 Material design and construction. Conformance to 3.3 through 3.3.2.3 and 3.4
shall be determined by inspection of contractor records providing proof or certification that
materials conform to requirements. Applicable records shall include drawings, specifications,
design data, receiving inspection records, processing and quality control standards, vendor
catalogs and certifications, industry standards, test reports, and rating data.
4.4.2 Examination. The hose assembly shall be examined for the defects specified in table
I.
TABLE I. Classification of defects.
Method of
Category
Defect
examination
Major:
Visual
101
Material not as specified (see 3.3).
Materials are not corrosion resistant or treated to be made
102
corrosion resistant for the applicable storage and operating
environment (see 3.3.1).
Visual
Dissimilar metals are not effectively insulated from each other
103
(see 3.3.1.1).
Visual
Contractor does not have documentation available for
104
identification of material; material finishes or treatments
(see 3.3.1.2).
Visual
Components missing (see 3.4).
105
Visual
Identificationof metal alloys not as specified (see 3.3.3).
106
Visual/Functional
Hose assembly not as specified (3.4.1).
107
Visual
Hose not as specified (see 3.4.2).
108
Visual/SIE
Dimensions and weight not as specified (see 3.4.2.1).
109
Visual/SIE
Hose to grooved adapter not as specified (see 3.4.3).
110
Visual
Bands not as specified (see 3.4.3).
111
Grooved couplings not as specified (see 3.4.4).
Visual
112
Marking missing, incomplete, or illegible(see 3.7).
Visual
113
Finish not as specified (see 3.8).
Visual
114
Workmanship not as specified (see 3.9).
Visual
115
Used, rebuilt, or remanufactured components pieces, or parts
Visual
116
incorporated into the hose assembly (see 3.10).
SIE = Standard Inspection Equipment.
10
