MIL-PRF-26626F
4.3 Conformance inspection. Conformance inspection shall include the individual tests
in 4.3.1 and the sampling tests in 4.3.2.
4.3.1 Individual tests. Each hose assembly shall be subjected to the following test:
a.
Examination (see 4.6.1).
b.
Proof pressure (see 4.6.2).
4.3.2 Sampling tests. Sampling tests shall be performed in accordance with guidance in
ASQC Z1.4. Sampling shall begin at the normal inspection level. The sampling tests are:
a.
Low temperature bending (see 4.6.7)
b.
Odor (see 4.6.9).
c.
Cleanliness (see 4.6.10)
4.4 Test conditions. Unless otherwise specified herein, all tests shall be performed in
accordance with test conditions specified below:
a.
Tests shall be performed at ambient atmospheric conditions.
b.
(1) Qualification inspections shall be performed with oxygen conforming to SAE
AS8010.
(2) Conformance inspections may be performed with either oxygen conforming
to SAE AS8010 or nitrogen conforming to A-A-59503.
c.
The torque applied to the AN818 nuts of the hose assembly shall be in accordance
with SAE ARP908.
4.5 Requirements cross-reference matrix. Table I provides a cross-reference matrix of
the section 3 requirements tested or verified in the paragraphs below.
TABLE I. Requirements cross-reference matrix
Requirement
Verification
Requirement
Verification
3.1
4.2
3.5.3
4.6.2
3.2
4.6.1
3.5.4
4.6.3
3.3
4.6.1, 4.6.11
3.5.5
4.6.4
3.3.1
4.6.1, 4.6.8, 4.6.9
3.5.6
4.6.5
3.3.2
4.6.12
3.5.7
4.6.6
6
