MIL-DTL-52471/8B
REQUIREMENTS:
The hose assemblies shall be as specified on figure 1 and in tables I through V.
Hose shall be in accordance with MIL-DTL-52471/7.
Connector fittings for hose assemblies shall be in accordance with MIL-DTL-52525.
PIN: The PIN consists of the letter "M", the specification sheet number, an assigned code number for
the hose assembly, material/plating designator, hose assembly length, and angular relationship of
fittings, when applicable.
52471/8
-C010
C
-098
-4
-135
M
Displacement angle of bent tube fittings
Angular relationship in degrees 1/
(Three digits use leading zeros as required)
See MIL-DTL-52471
1/8's of an inch length
(0 through 7)
Length of assembly in inches (see
MIL-DTL-52471) (Three digits use leading
zeros as required)
Material/plating see table V
Hose assembly code number
(See tables I through IV)
Specification sheet number
M prefix
1/ Not applicable for assemblies with straight fittings.
PIN example: M52471/8-C010C-098-4-135, describes a hose assembly consisting of M52471/7-8
hose, fitting X M52525/35-08-08, bend angle 45°, fitting Y M52525/35-08-08, bend angle 45°, steel
with cadmium plating, 98 ½ inches long, and a displacement angle of 135°.
To the users of this document, it is recommended that the use of carbon steel material with cadmium
plating be used only when the other materials and finishes specified in this document cannot meet
performance requirements.
Changes from previous issue. Marginal notations are not used in this revision to identify changes
with respect to the previous issue, due to the extent of the changes.
5
