MIL-DTL-52471/2C
REQUIREMENTS:
The hose assemblies shall be as specified on figure 1 and in tables I through X.
Hose shall be in accordance with MIL-DTL-52471/5.
Connector fittings for hose assemblies shall be in accordance with MIL-DTL-52525.
PIN: The PIN consists of the letter "M" the specification sheet number, an assigned code number for
the hose assembly, material/plating, hose assembly length, and angular relationship of fittings, when
applicable.
52471/2
-B216
C
-098
-4
-135
M
Displacement angle of bent tube fittings
Angular relationship in degrees 1/
(Three digits use leading zeros as required)
See MIL-DTL-52471
1/8's of an inch length (0 through 7)
Length of assembly (see MIL-DTL-52471)
(Three digits use leading zeros as required)
Material/plating see table X
Hose assembly code number
(See tables II through IX)
Specification sheet number
M prefix
1/ Not applicable for assemblies with straight fittings.
PIN example: M52471/2-B216C-098-4-135, describes a hose assembly consisting of M52471/4-6
hose, fitting X M52525/5-6-6, bend angle 0°, fitting Y M52525/6-6-6, bend angle 45°, steel with
cadmium plating, 98 ½ inches long, and a displacement angle of 135°.
To the users of this document, it is recommended that the use of carbon steel material with cadmium
plating be used only when the other materials and finishes specified in this document cannot meet
performance requirements.
