MIL-DTL-13531J
3.4.1.1 Type I. Reinforcement of type I hose shall consist of one braid of high-tensile steel wire (see
figure 1).
FIGURE 1. MIL-DTL-13531, type I, class A.
3.4.1.2 Type II. Reinforcement of type II hose shall consist of two or more braids of high-tensile steel
wire (see figure 2).
FIGURE 2. MIL-DTL-13531, type II, class A.
3.4.1.3 Type III. Reinforcement of type III hose shall consist of one braid of high tensile steel wire
covering two spiral plies of high-tensile steel wire (see figure 3).
FIGURE 3. MIL-DTL-13531, type III, class A.
6
