AN6270 REV 9
REQUIREMENTS:
The hose shall be a product that is listed on QPL-5593. The adapter shall be a product that is listed
on QPL-38726.
Hose assembly length "L" shall be specified with the following tolerances:
a. Less than 12 inches (304.8 mm) long (tolerance ±.12 (3.05 mm)).
b. 12 to 18 inches (304.8 to 457.2 mm) long (tolerance ±.25 (6.35 mm)).
c. Greater than 18 inches (457.2 mm) long (tolerance ±.50 (12.70 mm)).
The hose assembly shall be proof pressure tested in accordance with MIL-DTL-5593.
Materials shall be in accordance with MIL-DTL-38276, see table I for material designators.
TABLE I. Material designators.
Designator
Material
J
Corrosion resistant steel (CRES), type 304
K
Corrosion resistant steel (CRES), type 316
P
Chrome-molybdenum steel 4130
S
Steel 4140
T 1/
Titanium
W
Aluminum alloy 7075-T73
1/ Not to be used on oxygen systems.
Finishes shall be in accordance with MIL-DTL-38726, see table II for plating finish designators.
