INCH-POUND
A-A-59567/4
6 November 2104
COMMERCIAL ITEM DESCRIPTION
SPECIFICATION SHEET
HOSE ASSEMBLY, GARDEN, WATER, AND WATER SUCTION,
PIN LUG SWIVEL TYPE COUPLER
The General Services Administration has authorized the use
of this commercial item description for all federal agencies.
The complete requirements for procuring the hose assembly, garden, water, and water suction, pin lug
swivel type coupler described herein shall consist of this document and the latest issue in effect of A-A-
59567.
CLASSIFICATION/PART OR IDENTIFICATION NUMBER (PIN). This commercial item description (CID)
specification sheet uses a classification system which is included in the PIN as shown in the following
example (see NOTES).
AA59567
/4
-1
-1
-2D
STB
10
B
-080
Hose assembly length in feet
Coupling material code (see table IV)
Hose assembly size code (see table I)
Style 2 requires a clamp/ferrule designator
not applicable to style 8 (see table II or III)
Style, thread designator (see table II or III)
Hose class dash number
Hose grade dash number
Slash sheet number
CID number
SALIENT CHARACTERISTICS.
Interface and physical dimensions. Hose assemblies supplied to this CID specification sheet shall meet
the general requirements specified in A-A-59567 and be as specified herein (see figure 1).
Beneficial comments, recommendations, additions, deletions, clarifications, etc., and any data that may
improve this document should be sent to: DLA Land and Maritime, ATTN: VAI, P.O. Box 3990,
Columbus OH 432180-3990, or fluidflow@dla.mil. Since contact information can change you may want
to verify the currency of the address information using the ASSIST Online database at
AMSC N/A
FSC 4720
