A-A-55697B
1/ 2/ 3/
TABLE I. Inside/outside diameter and wall thickness of tubes.
4/
5/
Nominal ID
OD
nominal WT
Size code
(inches)
(mm)
(inches)
(mm)
(inches)
(mm)
01
0.125
(3.2)
0.1875
(4.8)
0.0313
(0.8)
02
0.1563
(4.0)
0.2813
(7.1)
0.0625
(1.6)
03
0.1875
(4.8)
0.3125
(7.9)
0.0625
(1.6)
04
0.2500
(6.4)
0.3750
(9.5)
0.0625
(1.6)
05
0.3125
(7.9)
0.4375
(10.5)
0.0625
(1.6)
06
0.3750
(9.5)
0.5000
(12.7)
0.0625
(1.6)
07
0.3750
(9.5)
0.6250
(15.9)
0.1250
(3.2)
08
0.5000
(12.7)
0.7500
(19.1)
0.1250
(3.2)
09
1.0000
(25.4)
2.0000
(50.8)
0.5000
(12.7)
1/ Dimensions are in inches.
2/ Metric equivalents are given for information only.
3/ Sizes other than those shown in table I may be ordered by specifying dimensional data in lieu of PIN
(see 7.1).
4/ Tolerance on inside diameter for all sizes shall be ±.0156 inch (0.4 mm).
5/ Tolerance on wall thickness for all sizes shall be - 0 or +.0156 inch (-0.00 or +0.4 mm).
3. SALIENT CHARACTERISTICS.
3.1 Interface and physical dimensions. Tubing supplied to this CID shall be as specified herein.
3.2 Material. Tubing provided in accordance with this CID shall be colorless, clear, and flexible PVC.
3.3 Dimensioning. The values stated in inch-pound units are to be regarded as the standard. The metric
values stated in parentheses throughout this CID are for informational purposes only and have been
rounded to only one decimal place for convenience.
3.4 Lengths. Tubing shall be furnished in the length specified in table II (see 7.5c).
1/ 2/
TABLE II. Tubing lengths.
Length code
Length
A
50 Feet
15.24 meters
B
100 Feet
30.48 meters
C
250 Feet
76.20 meters
D
500 Feet
152.40 meters
E
1000 Feet
304.80 meters
1/ Dimensions are in inches.
2/ Metric equivalents are given for information only.
3.5 Form. Tubing shall be furnished in the form specified in table III (see 7.5c).
TABLE III. Tubing forms.
Form code
Form
1
Coils
2
Reels
3
Straight
2
