MS8009C
FIGURE 6. Style F hose assembly. Hose assembly dimensions for style G: See table VIl.
TABLE VII. Hose assembly dimensions for style G. 1/
Fitting ends |
Hose size |
Dimensions 2/ |
|||
1 |
2 |
C (max) |
M (max) |
P (max) |
|
|
Straight |
Straight |
8 |
0.880 |
1.560 |
0.875 |
10 |
0.967 |
1.570 |
1.000 |
||
12 |
1.122 |
1.640 |
1.250 |
||
16 |
1.480 |
1.750 |
1.500 |
||
20 |
1.750 |
1.990 |
1.844 |
||
24 |
2.150 |
2.260 |
2.125 |
||
1/ Style G uses class 2 fittings which are made from a combination of aluminum and CRES.
2/ Dimensions are shown on figure 7.
FIGURE 7. Style G hose assembly.
5
