INCH-POUND

MIL-DTL-8788F

1 March 2011

SUPERSEDING

MIL-DTL-8788E

24 April 2007

DETAIL SPECIFICATION

HOSE, RUBBER, HYDRAULIC, HIGH PRESSURE (3,000 PSI),

OPERATING TEMPERATURE RANGE -65�F to +160�F

This specification is approved for use by all Departments and

Agencies of the Department of Defense.

1. SCOPE

1.1 Scope. This specification covers the requirements for hose, rubber, hydraulic, high pressure

(3000 psi) operating temperature range -65�F to +160�F (see 6.1).

1.2 Part or Identifying Number (PIN). The PIN consists of the letter M, the basic specification number,

a dash, a number for hose size, a dash, three numbers for length a dash, and a number for fractions of an

inch or for bulk hose lengths the letter B or S.

8788 -

096

Fractional lengths in 1/8 inch increments (1 thru 7)

(see 1.2.1.2) or B or S for bulk lengths (see 1.2.1.3)

Length in inches or feet (see 1.2.1.1 or 1.2.1.3)

Hose size dash number (see figure 1)

Specification number

M prefix

Comments, suggestions, or questions on this document should be addressed to: DLA Land and Maritime,

Columbus, Attn: VAI, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to FluidFlow@dla.mil. Since

contact information can change you may want to verify the currency of this address information using the

AMSC N/A

FSC 4720
